6QV-AF vertical froth pump: Specially Designed For froth Slurry
6QV-AF froth pump stands out in the froth pump market with its advantages such as efficient froth elimination, flexible drive mode, advanced material tank design, double casing structure, excellent self -suction ability, wide adjustment range, easy maintenance, strong wear resistance and corrosion resistance, etc., and is especially suitable for various flotation process. It is the deal choice for transporting froth like slurry.
Advantages
1.Efficient froth Removal
6SV-AF vertical froth pump can effectively eliminate the froth in the slurry during work, and can still work normally even when the feed is insufficient. It is especially suitable for various flotation processes and is an ideal product for transporting froth slurry.
2.Advantage Tank Design
The tank is made of steel structure or stainless steel, etc., and is equipped with a tangent entrance and overflow nozzle. The overflow nozzle can conveniently send the excess incoming material back to the tank, and the tangent entrance can quickly allow the material to enter the pump and eliminate part of the froth.
3.Double Casing Structure
The pump head structure is a double casing structure. Depending on the conveying medium, the wet-end parts can be made of metal, rubber or other non-metallic materials. This design not only improves the durability of the pump, but also adapts to the conveying needs of different media.
4.Strong Self-suction Ability
The 6SV-AF froth pump has excellent self-suction ability, which can quickly inhale and transport the froth mixture without an external water transfer device. This feature makes the pump more flexible and reliable in the complex and changeable field environment, reducing the complexity of installation and operation.
5.Easy To Maintain
The design of the 6SV-AF froth pump considers ease of maintenance, and many key parts such as bearings, seals, etc., can be easily disassembled and replaced. In addition, the frame plate is compact, which is easy to clean and inspect, reducing the difficulty and cost of maintenance.
6.6SV-AF froth Pump Performance Parameters
Installed With Power P（KW）：15-75
Flow Q（m³/h）：80-393
Head H（m）：5-25
Speed n（r/min）：250-680
Efficient η%：55
Inlet（mm）：200
Outlet（mm）：150
Model | Power | Capacity | Head | Speed | Eff. | Inlet dia. | Outlet dia. |
P(KW) | Q(m3/h) | H(m) | n(r/min) | ŋ% | (mm) | (mm) | |
2QV-AF | 3-15 | 6-43 | 6-30 | 800-1800 | 45 | 100 | 50 |
3QV-AF | 3-18.5 | 23-78 | 5-28 | 700-1500 | 55 | 150 | 75 |
4RV-AF | 5.5-37 | 33-187 | 5-28 | 500-1050 | 55 | 150 | 100 |
6SV-AF | 15-75 | 80-393 | 5-25 | 250-680 | 55 | 200 | 150 |
8SV-AF | 37-110 | 126-575 | 5-26 | 350-650 | 55 | 250 | 200 |
